Lumami® DESK
Lumami® DESK has the advantages of a pendant lamp, combined with the individuality of a desk lamp and the high performance of further lighting systems like grid ceiling or floor luminaires, for ideal workplace lighting, in compliance with DIN standard EN 12464-1
Lighting intensity >750 lux
Glare limitation through UGR <16
Uniformity through special developed optic for Lumami® DESK
At first glance, this may look like something you need to get used to and it may raise some questions... and that‘s what it‘s supposed to do!
But from the result you will be convinced!
light source
Separate light source LTwo® (3000K and 4000K) with special developed asymmetric-batwing optic. Lengths: 840mm and 1400mm
magnetic luminaire holder
Magnetic lamp holder: tool-free installation of the light source, for easy installation, replacement and maintenance. Optimal alignment due to adjustability of light source in 5-degree steps. Maximum adjustment: 20 degrees to two sides, for optimal alignment. Additional brackets to secure LTwo® from falling down
free placement
Standalone version for free placement of Lumami® Desk on the table. Luminaire base with pen tray and space for dimm-wheel. Clamp version for direct mounting on the table.
luminaire head
Luminaire head with integrated presence detector. Without presence, the light is dimmed to 10% of the total power after 15 minutes. After a total of 30 minutes, the light turns off automatically.
usb-c
An USB-C interface enables the connection of additional electrical devices.
dimm-wheel
Separate dimm-wheel for switching on and off and regulate the light intensity. It can be dimmed between 10%-100% (the dimm-wheel is already preconfigured for tunable white versions to adjust the color temperature).
plug-in
Separate plug-in power supply (48V DC) for connection to mains.
benefits
- replaceable light source
- replaceable power supply
- always the same illumination even with height-ad justable desks
- no space problem in the room, as it is positioned on the desk
- easy relocation in case of new office configuration due to low weight
workplace
lighting
Which requirements do we face for workplace lighting
The lighting of office workplaces requires special attention and care.
It is therefore regulated by DIN standard EN 12464-1 - Lighting requirements for people at workplaces in indoor areas.
benefits
for ideal homogeneity
The specially developed optic for Lumami® DESK enables homogeneous illumination of the entire workspace.
In combination with the length of the light source (1400mm or 840mm are recommended), Lumami® DESK meets the requirements of DIN standard EN 12464-1 with regard to the illumination of the direct work surface (up to >750 lux), and the adjacent work surfaces (>300 lux), as well as the UGR (<16).
In addition, the lamp can still be tilted by +/- 20 degrees (in 5-degree increments) when installed. This ensures additional lighting comfort through individual alignment.
for ideal opportunities
Available as a stand-alone version for free positioning on the desk or as a clamp version for mounting on the table, Lumami® DESK can be easily set up or mounted. The separate light source LTwo® is easily attached to Lumami® DESK using the magnetic plug. Ready!
The exchangeability of the illuminant not only contributes to sustainability, but also enables simple installation, easy maintenance and the exchange of the illuminant depending on the taste and application of Lumami® DESK.
less weight for ideal sustainability
With the minimal design of the luminaire and the light source and thus a significantly reduced use of materials, Lumami® DESK makes a significant contribution to the responsible use of raw materials. In comparison, a conventional floor luminairweighs about 20 kg, Lumami® DESK just 4,3 kg. Thanks to APL‘s own illuminant, the LED becomes an interchangeable object. This means that the entire luminaire no longer has to be replaced, only the light source. The power supply can also be exchanged, since it is not permanently installed with the luminaire, for less electronic waste.
Sustainable from start to end:
- Less materials
- Less weight (78,5% compared to floor lamps)
- Lower carbon footprint
- Easy maintenance
- Easy disposal
Sustainability all along the line, that is important to us!
plant-my-tree
As a partner of Plant-My-Tree, we contribute to the reforestation of the forests in the southern Harz region. For every Lumami® DESK sold, Plant-My-Tree plants a tree in this region. Our green contribution to a balanced eco-system.
With the help of many partners, PLANT-MYTREE® has already given life to more than 1,000,000 trees, as well as connecting more than 60 different projects throughout Germany.
Lumami® DESK
Stand-alone & Clamp
Stand-alone version for free placement
- Black
- White
- Champagne-Bronze
Clamp version for desk mounting
- Black
- White
- Champagne-Bronze
product
portfolio
|
Illuminant LED |
APL LTwo® - Monowhite / Tunable white |
|
Mounting type |
Desk - Stand Alone or Clamp |
|
Light distrubtion |
Batwing wide |
|
Luminaire luminous flux |
797 lm @842 mm / 1328 lm @1402 mm |
|
Color temperature |
3000K or 4000K |
|
Power |
10 Watt (LTwo® 842 mm) 16,8 Watt (LTwo® 1402 mm) |
|
Color rendering index (CRI) |
>90 |
|
Suitable for VDU workstations |
yes - DIN-EN 12464-1 compliant |
|
UGR |
<16 |
|
Rated voltage |
220-240V |
|
Mains frequency |
50-60 HZ |
|
Surface |
White (powder coated); Black or Champagne-bronze (anodized) |
|
Control |
Remote dimm-wheel |
|
Material of the housing |
aluminium |
|
Control gear included |
yes |
|
Protection class |
IP20 |
|
Number of lamp heads |
1 x APL LTwo® |
|
Energy efficiency LTwo® |
black 78 lm/W, white 100 lm/W |
|
Dimmable |
Yes – dimmable with seperate dimm-wheel (included) |
|
Type of dimming |
dimm-wheel (PWM) |
|
Material of the anti-glare |
plastic-white: ASA; black: ABS |
|
Length of connecting cable |
1,5m |
|
Luminaire head rotatable |
yes - max. 20° forward and backward in 5° steps |
use
case
A typical workplace situation in an office.
In direct lighting, Lumami® Desk provides ideal and homogenious illumination of your own work surface and can be adapted by each person to their individual needs. No disturbing lighting for other people in the room.
The individual control and the presence sensor protect from unnecessary energy consumption. The lighting comfort does not change even with height-adjustable desks, since the luminaire changes height with the desk.
No wasted space or consideration of lamp bases as with heavy free-standing lamps, for more flexibility in the room and less interventions in the architecture.
some words
about LTwo®
The APL Light Source used in Lumami® DESK
Lumami® DESK uses APL‘s own light source LTtwo®, which turns into an exchangable object, for more sustainability in dealing with lighting.
Additionally the LTwo® lamp-luminaire-system enables the overall lighting of offices.
Installed with simple accessories and with 13 different optics, such as e.g. the APL wallwasher, the system can e.g. flood cupboards and walls. It contributes to greater clarity and, thanks to the vertical lighting, to more comfort.
Skilfully staged pictures, documents and certificates create a pleasant room atmosphere. The equal lighting design creates a coherent and uniform lighting concept and thus more comfort at offices.
